Cement-bound, polymer-modified universal screed with good levelling quality for filling and levelling substrates up to 10 mm thick (up to 20 mm when laced with quartz sand). Also suitable for asphalt screeds with a hardness class of IC 10, in layers up to 5 mm thick.

ServoMulti S 110 is suitable as a substrate for laying ceramic floor coverings, natural and artificial stone, and elastic and textile floor coverings.

ServoMulti S 110 cannot be used as a subfloor or in wet rooms.

The substrate must be inspected and ready for installation in accordance with the respective regulations of the individual countries as well as the current state of technology. Substrates must be pre-treated in accordance with the current BEB datasheet ('Evaluation and Preparation of Substrates').

Depending on the type of substrate, floor coverings and the requirements such as subsequent loading conditions prime substrate with: Okatmos® GGS, Bakit PV-Universal, Okatmos® UG 30, Okatmos® EG 20, Okatmos® DSG, Okamul PU-V schnell or Okapox GF. On calcium sulfate based screeds exceeding 10 mm use Okamul PU-V schnell or Okapox GF primers.

The technical data sheets for the products used must be observed.

A system structure assembly must be provided.

Mix ServoMulti S 110 with clean water at a maximum speed of 600 rpm, using an electric mixer, until there are no clumps. Leave to stand for approx. 5 minutes and then mix again. Next, apply the screed with a trowel or a scraper. Avoid direct sunlight and draughts during the drying period. Lay some screed as a practice, in case of doubt.

Color

grey

Application

indoors, on floors

Thickness

1 - 10 mm

10 - 20 mm when laced with quartz sand

max. 5 mm on asphalt screeds

Aggregate

possible from 10 mm

8 kg quartz sand (grain size 0.6-1.2 mm) per 25 kg of powder

Chair caster suitability

suitable from 1 mm layer thickness (in accordance with DIN EN 12 529)

Water demand

approx. 6.0 - 6.5 litres per 25kg powder

Processing time*

approx. 40 minutes

Walkable*

after approx. 2 hours

Ready for installation*


Surface coveringthickness in mmafter approx.
elastic and textile coverings 1-10 / 10-20**24 h / 48 h**
ceramic floor coverings 1-10 / 10-20**4 h / 4 h**
natural stone floor coverings 1-10 / 10-20**24 h / 48 h**
** with aggregate
Floor heating system

suitable

GISCODE

D1 in accordance with TRGS 610

EMICODE®

EC 1R in accordance with GEV

Storage

store in a dry place; can be stored for approx. 6 months

*

At +20°C and 65% relative humidity. High temperatures and low humidity lower this value, while lower temperatures and higher humidity increase it.

approx. 1.5 kg/m²

Clean tools immediately with water.

Product descriptionItem no.Item no.
42 x 25 kg paper bags420194015705420196

The above data, particularly any recommendations for mixing and using our products, is based on our knowledge and experience. Due to different materials and working conditions which are beyond our control, we strongly recommend that you carry out enough tests in each case to ensure the suitability of our products for the intended processes and purposes. No liability can be assumed from this information or any verbal recommendation, except in the case of wilful intent or gross negligence on our part. All previous versions of this information are rendered invalid following the publication of this technical data sheet.

The aforementioned information, especially the proposals for processing and utilizing our product, is based on our knowledge and experience. We recommend that you carry out your own tests in every case to ensure the suitability of our products for the intended process and processing purposes because of the different materials and the working conditions which lie beyond our area of influence. No liability can be derived from this advice or from verbal advice, unless we are responsible for (criminal) intent or gross negligence in this respect.


Revised: 20.10.2022/ag
