Datasheet

EC1 Plus_GB_black

Solvent-free, very low-emission wet- and pressure-sensitive adhesive for bonding homogeneous and heterogeneous Vinyl-coverings such as sheet and tile format, CV-coverings, LVT-coverings, rubber flooring up to 4.0 mm in sheet and tile format, linoleum up to 3.2 mm and textile floor coverings. Okatmos® star 200 can be used as a wet-bed and pressure-sensitive adhesive as well as in the contact bonding process (double-drop). With its hygienising effect, Okatmos® star 200 helps to avoid odours.

The substrate must be inspected and ready for installation in accordance with the respective regulations of the individual countries as well as the current state of technology. Substrates must be pre-treated in accordance with the current BEB datasheet ('Evaluation and Preparation of Substrates').

Depending on the type of substrate, floor coverings and the requirements such as subsequent loading conditions prime substrate with: Okatmos® EG 20, Okatmos® UG 30, Okatmos® DSG, Okamul PU-V schnell or Okapox GF and prepare with suitable Kiesel levelling compound. When installing vapor-tight floor coverings as well as over non-absorbent substrates, apply the levelling compound thick enough. The technical data sheets of the products used must be observed. Kiesel system products must be used.

Stir Okatmos® star 200 well. Use appropriate notched trowel to apply the adhesive onto the substrate. Depending on the quantity applied, the absorbency of the substrate and the type of covering, allow the adhesive to dry. Only apply as much adhesive as can be covered with floor covering within the open time.
On non-absorbent substrates, you can only achieve a pressure sensitive adhesion.
After the waiting time, install the covering without air pockets and carefully rub down over the entire surface. If the covering starts to rise again after being rubbed down, do not rub it down again until approx. 30 minutes have passed. The installation instructions of the flooring manufacturer, especially the instructions for acclimatisation, must be followed.
Weld or seal the floor coverings after 24 hours at the earliest.

 absorbent, plastered surfacesdense, non-absorbent substrates


wet bed process

semi-wet process

pressure-sensitive adhesive process

contact bonding process

(Double-Drop)

covering

PVC-coverings

CV-coverings

Vinyl-covering

rubber flooring

Linoleum

textile floor coverings

LVT-coverings

CV-coverings

Wall coverings

LVT-coverings

CV-coverings

Wall coverings

trowel size

TKB A2

TKB B1

TKB A5TKB A5
waiting time5 - 30 minutes30 - 40 minutes

10 - 15 minutes

resume covering again



after 20 - 25 minutes

resume covering again

curing time20 - 40 minutes50 - 120 minutes35 - 40 minutes

Color

cream white

Application

interior, on walls and floors

Suitable for chair castors (DIN EN 12529)

suitable

Minimum floor temperature

+ 15 °C (59 °F)

Skin over time* / Tack time

/ Waiting time*

approx. 5-40 minutes

Open time (working)

approx 5-120 minutes

Ready for traffic*

after approx. 24 hours

Final strength*

after approx. 72 hours

Floor heating system

suitable

GISCODE

D 1 according to TRGS 610

EMICODE

EC 1Plus

Storage

store in frost protected area for up to 12 months

At 68 °F (+20 °C) and 65% relative humidity. Higher temperature and low humidity decreases, lower temperature and high humidity increases this value respectively.

  • The floor coverings must be sufficiently free of tension, acclimatized, and must be adapted to the ambient room conditions prevailing in its subsequent use. Observe the relevant advice and information given by the floor covering manufacturers.
  • Areas of flooring subject to strong roll tension, raised edges or warps, creases formed from folding or squashing must be weighed down during the installation until the adhesive has set.
  • If exposed to strong temperatures, e.g. sunlight in a conservatory or on window fronts, if subjected to heavy mechanical stress from floor trucks or fork lifts etc., or if exposed to moisture from above, the use of Okamul PU would be preferable or seek application-technical advice.
  • In case of standard floor covering, follow guidelines which generally accept rules of the subject and installation techniques, as well as the current standards and information sheets.
Trowel SizeType of coveringCoverage

TKB A2

TKB A5

CV covering

Approx. 250 - 300 g/m²

Approx. 200 - 250 g/m²

TKB A2

PVC-covering

Vinyl-covering

Rubber flooring

Approx. 250 - 300 g/m²
TKB B1

Linoleum

textile coverings

Approx. 300 - 350 g/m²

The coverage depends, among other things, on the substrate properties and may vary with different levelling compounds, trowel manufacturers and processing methods.

Clean tools with water immediately after application.

Product descriptionItem no.Item no.
33 x 14 kg plastic buckets491124015705491127

The medium or long-term release of significant concentrations of volatile organic compounds (VOCs) into the room air is not to be expected. Nevertheless, thorough ventilation should be ensured during and after processing and drying.

Eating, drinking and smoking should be avoided while processing the product. In case of contact with eyes or skin, rinse immediately with plenty of water. Do not allow to enter drains, waterways or soil.

Product contains 2-methyl-2H-isothiazol-3-one (MIT) / 1,2-benzisothiazol3(2H)-one (BIT).

Information for allergy sufferers on Tel. 0711/93134-0.

Keep out of reach of children.

Disposal: The product must not be allowed to enter water, waste water or soil. Only recycle packaging when completely empty. Dispose of hardened product residues as commercial waste similar to household waste. Containers with liquid residues are hazardous waste.

Components: Plastic dispersion, thickening, wetting, defoaming and preservative agents, rosin resin derivatives, mineral fillers, water

The aforementioned information, especially the proposals for processing and utilizing our product, is based on our knowledge and experience. We recommend that you carry out your own tests in every case to ensure the suitability of our products for the intended process and processing purposes because of the different materials and the working conditions which lie beyond our area of influence. No liability can be derived from this advice or from verbal advice, unless we are responsible for (criminal) intent or gross negligence in this respect.


Revised: 27.02.2025/ag
